Product code:90-03-00
New in
Ask a question
Write your opinion
Technical specification
Brand
Symbol
90-03-00
Producer code
5902730174639
Type
Automatic
Application
cars and car-derived vans
Rim diameter
10" - 24"
ALU wheel programs
3
Rim width
1,5" - 20"
Power source
230V 50Hz
Hidden weight program
YES
Auto-ALU (choosing the spot for adhering weights)
ALU-S
Voice synthesizer
none
Max wheel weight
65 kg
Measuring cycle time
8 seconds
Shaft diameter
36mm (diameter) x 3mm (thread pitch)
Operators' memory
no
Rotating torque
200 RPM
Noise level
< 70 dB
Min imbalance
1g
Power
0,2 kW
Display
LED
Shaft blocking
Electromechanic brake
Additional options
ALU-S Programme
Autocalibration
Optimisationi
Optimisation is for lowering the number of weights to be mounted onto the rim, so that the tyre is located on a rim i a way that the rim's imbalance is equal to tyre's imbalance, which minimizes the wheel imbalance.
Maximum energy consumption
0,2kW
Lift
no
Imbalance positioning
LED lights, sound signal
Automatic data entering
diameter; distance
Standard equipment
1x Pliers
1x Calibration clip-on weight 100g
1x quick-nut
1x Small bushing
1x Large bushing + rubber
1x plastic caliper
1x threaded shaft 36*3
1 x Paper manual
4x Cones (43-65,55-86,84-103,94-135)
3x cones hanger
1x wheel cover
Dimensions
1097 x 737 x 1500 mm
Weight
76 kg
Extra functions
-
Manufacturer
REDATS
Warranty
24 months (extension possible)
Warranty (for companies)
12 months (extension possible)
