Product code:90-03-09
New in
Ask a question
Write your opinion
Technical specification
Brand
Symbol
90-03-09
Producer code
5902730175414
Type
semi-automatic
Rim diameter
10" - 24"
Rim width
1,5" - 20"
Application
cars and car-derived vans
Power source
230V or 12V
Hidden weight program
YES
ALU wheel programs
3
Auto-ALU (choosing the spot for adhering weights)
no
Voice synthesizer
none
Max wheel weight
65 kg
Shaft diameter
36mm (diameter) x 3mm (thread pitch)
Measuring cycle time
8 seconds
Operators' memory
no
Rotating torque
ca. 120 RPM
Noise level
< 70 dB
Power
not applicable
Display
LED
Min imbalance
1g
Shaft blocking
handbrake
Additional options
Autocalibration
Optimisationi
Optimisation is for lowering the number of weights to be mounted onto the rim, so that the tyre is located on a rim i a way that the rim's imbalance is equal to tyre's imbalance, which minimizes the wheel imbalance.
Maximum energy consumption
50 W
Lift
no
Imbalance positioning
LED lights, sound signal
Automatic data entering
no
Standard equipment
Calibration counterweight
caliper
pliers
Quick release wing nut
metal support allows installing to changer's casing
Large bushing with rubber
Small bushing
3 centering cones (43 mm - 135 mm)
shaft 36x195 with mounting thread
3 hangers with plastic pads
Allen wrench with handle
Car lighter cable
Dimensions
974 x 430 x 903 mm
Weight
50 kg
Extra functions
Perfect for mobile tyre service
Manufacturer
REDATS
Warranty
24 months (extension possible)
Warranty (for companies)
12 months (extension possible)
