Product code:90-02-67
New in
Ask a question
Write your opinion
Technical specification
Brand
Symbol
90-02-67
Producer code
5902730172352
Type
Automatic
Application
cars and car-derived vans
Rim diameter
10" - 24"
Rim width
1,5" - 20"
ALU wheel programs
4
Power source
230V 50Hz
Hidden weight program
YES
Auto-ALU (choosing the spot for adhering weights)
yes
Voice synthesizer
none
Max wheel weight
65 kg
Measuring cycle time
8 seconds
Shaft diameter
36mm (diameter) x 3mm (thread pitch)
Rotating torque
200 RPM
Operators' memory
no
Noise level
< 70 dB
Power
200W
Display
LED
Min imbalance
1g
Additional options
SPLIT
Autocalibration
Optimisationi
Optimisation is for lowering the number of weights to be mounted onto the rim, so that the tyre is located on a rim i a way that the rim's imbalance is equal to tyre's imbalance, which minimizes the wheel imbalance.
Autodiagnosis
weight mounting arm
Shaft blocking
Foot brake, electromechanic brake
Maximum energy consumption
200 W
Lift
no
Imbalance positioning
LED lights, sound signal
Automatic data entering
yes - distance, diameter
Standard equipment
1x Pliers
1x Calibration clip-on weight 100g
1x quick-nut
1x Small bushing
1x Large bushing + rubber
1x plastic caliper
1x threaded shaft 36*3
1 x Paper manual
3x cones hanger
1x wheel cover
4x Cones (43-65,55-86,84-103,94-135)
1x screen
Dimensions (height x depth x width)
1253 x 817 x 1619 mm
Weight
97 kg
Extra functions
-
Manufacturer
REDATS
Warranty
24 months (extension possible)
Warranty (for companies)
12 months (extension possible)
