Product code:90-03-17
New in
Ask a question
Write your opinion
Technical specification
Brand
Symbol
90-03-17
Producer code
5902730175827
Type
Automatic
Application
cars and car-derived vans
Power source
230V 50Hz
Runflat/Low profile tyres
yes
Internal jaw spacing range
14" - 26"
External jaw spacing range
12" - 23"
Max. wheel diameter
1143 mm
Maximum wheel width
406 mm
Bead breaker shovel force
2500 kg
Power
I gear: 0,75 kW, II gear: 1,1 kW
Working Pressure
8 - 10 Bar
Noise level
< 75 dB
Engine speed
I speed: 1360 RPM
II speed: 2630 RPM
Turntable max. torque
1078 Nm
Table rotation speed
I speed: 6 RPM
II speed: 12 RPM
Blocking of the arm and head
Pneumatic
Standard equipment
Oil lubricator + air preparation unit
Inflation gun with manometer
Plastic caps for tyre changer (roller and duckhead)
Plastic jaw caps 4 pcs
Tyre lever
Accessories bucket
Arm 3D2 ( 2x roller, centering cone)
Third hand clamp
Plastic bead breaker shovel protector
Nakładka na rant felgi
Weight
ok. 285 kg
Dimensions (height x depth x width)
198 x 112 x 98 cm
Manufacturer
REDATS
Warranty
24 months
Additional options
2-speed motor, 3D2 arm, RUNFLAT
Warranty (for companies)
12 months
