Product code:90-01-13
Ask a question
Write your opinion
Technical specification
Brand
Symbol
90-01-13
Producer code
5902730157335
Type
semi-automatic
Rim diameter
10" - 24"
Rim width
1,5" - 20"
Application
cars and car-derived vans
Power source
230V 50Hz
Hidden weight program
none
ALU wheel programs
3
Auto-ALU (choosing the spot for adhering weights)
none
Voice synthesizer
none
Max wheel weight
65 kg
Measuring cycle time
8 seconds
Shaft diameter
36mm (diameter) x 3mm (thread pitch)
Operators' memory
none
Rotating torque
80 RPM
Noise level
< 70 dB
Power
not applicable
Display
LED
Min imbalance
1g
Shaft blocking
pedal brake
Additional options
Autocalibration
Maximum energy consumption
50 W
Lift
no
Imbalance positioning
LED lights
Automatic data entering
none
Standard equipment
4x Cones (43-66,65-85,84-102,94-135)
1x Pliers
1x Calibration clip-on weight 100g
1x Nakrętka szybkomocująca (do napędu ręcznego)
1x Small bushing
1x Large bushing + rubber
1x plastic caliper
1x threaded shaft 36*3
1 x Paper manual
3x cones hanger
Dimensions (height x depth x width)
766 x 455 x 903 mm
Weight
47 kg
Extra functions
Light and compact
Manufacturer
REDATS
Warranty
24 months (extension possible)
Warranty (for companies)
12 months (extension possible)
