Product code:90-01-36
Ask a question
Write your opinion
Technical specification
Brand
Symbol
90-01-36
Producer code
5902730157526
Type
Automatic
Rim diameter
10" - 24"
Rim width
1,5" - 20"
Application
cars and car-derived vans
Power source
230V 50Hz
Hidden weight program
YES
ALU wheel programs
9
Auto-ALU (choosing the spot for adhering weights)
yes
Voice synthesizer
none
Max wheel weight
65 kg
Measuring cycle time
8 seconds
Shaft diameter
40mm (diameter) x 3mm (thread pitch)
Operators' memory
no
Rotating torque
200 RPM
Noise level
< 70 dB
Power
200W
Display
LED
Min imbalance
1g
Shaft blocking
Electromechanic brake
Additional options
SPLIT
Autocalibration
Optimisationi
Optimisation is for lowering the number of weights to be mounted onto the rim, so that the tyre is located on a rim i a way that the rim's imbalance is equal to tyre's imbalance, which minimizes the wheel imbalance.
Autodiagnosis
Automatic positioning of imbalance points
Lift
no
Imbalance positioning
sound signal
Automatic data entering
yes - distance, diameter, width
Standard equipment
4x Cones (43-66,65-85,84-102,94-135)
1x Pliers
1x Calibration clip-on weight 100g
1x quick-nut
1x Small bushing
1x Large bushing + rubber
1x plastic caliper
1 x Paper manual
3x cones hanger
1x Threaded shaft 40*3
1x wheel cover
Dimensions (height x depth x width)
1252 x 843 x 1624 mm
Weight
109 kg
Manufacturer
REDATS
Warranty
24 months (extension possible)
Extra functions
Laser
Warranty (for companies)
12 months (extension possible)
